The new Dan-Chief Cat 8.1 Solutions provide the highest level of copper infrastructure that will meet your current and future data center requirements. Our Category 8.1 cabling components support up to 25 Gb/s in the data center physical layer with two-connector channels up to 30 m in distance. The transmission frequency is raised to 1600 MHz –with a leeway up to 2000 MHz. Dan-Chief’s Cat 8.1 Solutions for the universal RJ-45 connecting interface used in today’s data center follow ANSI/ITA standards and are in accordance with ISO/IEC specifications.
Dan-Chief Cat 8.1 tool-less termination connector series is a future-proof solution with many great features.
- About
-
Products
- Work Area
- Telecom/Equipment Room
- Modular Plug and Patch Cord
- Tools and Accessories
- Fiber
- Smart Wi-Fi and Media
- Rigid Industrial Ethernet (IP68)
- Solutions
- News
- Support
- E-catalog
- Contact Us
- 繁體中文
-
Solutions
- Home
- Solutions
- Category. 8
- Cat. 8 Solutions
- 101S001D01
101S001D01
CATEGORY 8 STP FIELD TERMINATION PLUG
MATERIAL
Shield contact ： nickel silver alloy.
Plug housing ： zinc alloy, nickel plated.
Contact holder : PC, UL94V-0.
Plug contacts : phosphor bronze, 50U" gold plated on contact area.
IDC plastic : PC, UL94V-0
IDC teminals : phosphor bronze, tin over nickel undercoat.
PHYSICAL
Insertion life : 750 mating cycles.
Plug retention force : 11 LBF minimum.
Insertion force : 30 N maximum.
Re-termination : up to 20 times.
Contact compatibility : Accommodates 22 to 26 AWG solid or stranded.
Cable jacket diameter : 6.5mm to 8.5mm
Operating temperature range : -10°C to 60°C
Storage temperature range : -40°C to 68°C
Humidity : 10% to 90% RH (non-condensing)
ELECTRICAL
Insulation resistance : 500MΩ minimum.
Voltage proof (contact to contact):1000 V AC.
Voltage proof (contact to shield) :1500 V DC.
DC current rating : 1.5Amps.
Input to output DC resistance : 100MΩ maximum.
Contact resistance : 20 MΩ maximum.
.png)
- A small sized keystone jack for better termination experience.
- Ideal for high density usage with a short-depth keystone jack for better space arrangement
- Category 8, channel-rated performance that will be beyond your expectations.
- High frequency and bandwidth that ensure your Data Center remains ‘up to the task’ in a rapidly evolving ICT Technology.
- A "FORCE" verified products that exceed all permanent link and channel applications.
