3012IPRLV50XX

Voice panel, 110/KRONE IDC, 1U50 Port


  • Color Option


PHYSICAL CHARACTERISTICS

Contact compatibility : accommodates 22 to 24 AWG solid.
Operating temperature range : -10°C to 60°C.
Storage temperature range : -40°C to 68°C.
Humidity : 10%~90%RH.

ELECTRICAL CHARACTERISTICS

Insulation resistance : 500 MΩ.
Dielectric withstanding voltage : 1000 V AC.
DC current rating : 1.5 Amps.
DC resistance : 0.1 Ω.
Contact resistance : 20 MΩ.


NOTES

Only compatible with RJ-45 8P8C plug.
